model: BS4500iE
3500-watt medium inverter generators with quiet technology
within 25 days delivery time after receiving the deposit！
BISON’s 3500-watt medium inverter generators with quiet technology provide reliable power. It operates at a low noise level (52-64 dB), making it ideal for use in environments where minimal noise is required.
features
legendary performance
Equipped with a 223cc, 1-cylinder, 4-stroke, air-cooled motor and a 12L fuel tank, it is capable of running for up to 18 hours at 25% load.
This generator is easy to use, with electric and recoil start options, as well as a wireless remote control for convenient operation.
It features a rugged design, including a heavy-duty steel frame and cast iron cylinder liners, ensuring durability and long-term reliability.
Weighing only 38 kg, this generator is compact and portable, making it easy to transport and store.
specifications
| output | |
| Rated power | 3.5 KW |
| Maximum power | 4.0KW |
| Phase | Single-phase |
| AC voltage | Depends on your country’s voltage |
| Single-phase AC amperage | Running power ÷ Using voltage |
| DC USB output | 5V/1A/2.1A |
| Frequency | 50 / 60 HZ |
| Noise level | 64dB with 7M |
| 100% load continuous operating time | 8.0 H |
| engine & emission | |
| Engine type | 1-cylinder, 4-stroke, air-cooled, veritical |
| Engine model name | BS225i-3 |
| Bore × stroke | 70 × 58MM |
| Engine displacement | 223 CC |
| Engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| Recoil start | Yes |
| Electric start | Yes |
| Remote control | Yes |
| alternator | |
| Winding material | 100% copper winding |
| Power factor | 1.0 (Single-phase) |
| fuel system | |
| Fuel tank capacity | 12 L |
| Oil capacity | 0.6 L |
| package | |
| Carton dimensions | 650 × 490 × 580 MM |
| Generator net weight | 38 KGS |
| Carton gross weight | 40 KGS |
optional
The open type inverter generators above 3 kilowatts should choose this option.
electric & remote start
easy to start the generator
The generators above 5 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
When you would like the generators use gasoline or LPG that you can choose this optional
Dual fuel
Double fuel with ECO
When you would like the power more than 10 kilowatts, you could choose this. It is not necessary for small kilowatts.
parallel connection
Bigger power more than 10.0 kilowatts
factory
overview
how we test the inverter generator
Ensure no air leaks from cylinder head.
cylinder head checking
Ensure the crankshaft installation with correct angle.
crankshaft torque
Ensure correct operation with next step.
remarks for camshaft
Ensure crankcase with strong thickness.
crankcase quality testing
Ensure the correct gap between intake and exhaust valves.
intake & exhaust valves gap
Ensure the sealing of the engine is stable.
air tightness test
Ensure the inverter is in correct position.
checking & adjustment the inverter position
Ensure the correct speed and power of engine.
testing speed
Ensure the gap between alternator and igniter.
gap of alternator
Ensure no mistake with inside and smoothly with recoil starter.
checking and recoil starter testing
Ensure no other spare parts inside silent box.
installing silent box and checking inside again
Ensure the rated power output.
power testing
Ensure sockets has rated current output
sockets current
Ensure all generators are working powerful before the package.
strengthen testing
Ensure no parts miss before the package
checking weight
