300kva dual-voltage 220v 380v three phase genset
300kva dual voltage 220v 380v three phase genset is manufactured with precision and efficiency in mind, delivering superior fuel efficiency.
Unleash ultimate power and versatility with PERKINS’ industrial-grade 300kva diesel gensets. This three-phase power supply provides seamless power switching between 220V and 380V to meet the diverse needs of the most demanding applications.
features
why choose PERKINS 300kva dual voltage genset?
Our 300kva behemoth handles heavy-duty operations with ease, providing reliable backup power for construction sites, factories, data centers and more.
Designed for three-phase balanced power distribution, ensuring optimal performance from equipment designed for three-phase operation.
Advanced engine technology, powered by the 1506a-e88tag5 engine, offers high performance and fuel efficiency, consuming only 65 liters per hour at 100% prime power. Its durable construction guarantees a long service life, providing an excellent return on investment.
- The high-quality hcI444d alternator ensures 88.50% power efficiency, with a brushless design and H-class insulation ensuring consistent performance.
- Precision control systems with the advanced DeepSea dse 7320 controller offer a user-friendly interface for easy monitoring, with optional remote access for monitoring from any location.
- Integrated safety features like alarms and automatic shutdown protect against electrical faults.
- Environmentally compliant, the BS-PS300 meets international emission standards and offers sound-attenuated enclosures for quiet operations, making it suitable for noise-sensitive environments as well.
specifications
| output | |
|---|---|
| rated power | 240 KW / 300 KVA |
| voltage | 220 V / 380 V |
| frequency | 50 HZ |
| Phase / Wire | 3 Phase / 4 Wire |
| Power Factor | 0.8 |
| engine & emission | |
|---|---|
| engine type | 1506A-E88TAG5 |
| type | Water-cooled, inline, 4-stroke, direct injection |
| prime power | 267 KW |
| intake type | Turbocharged aftercooled |
| no.cylinders | 6 |
| bore × stroke | 112 × 149 MM |
| displacement | 8.8 l |
| 100% prime power fuel consumption | 65 L/H |
| alternator | |
|---|---|
| brand model | HCI444D |
| prime power | 240 KW / 300 KVA |
| power efficiency | 88.50% |
| voltage regulation | ≤ ±1 |
| excitation type | brushless |
| insulation class | h |
| controller | |
|---|---|
| band | deepsea |
| model | DSE7320 |
| packaging | |
|---|---|
| dimension | 3950 × 1400 × 2000 MM |
| weight | 2500 KGS |
optional
When you take genset as backup power, you could choose this.
ATS
automatically start without human intervention required.
You should choose this option when the lowest temperature of the year in which the gensets are used is below 0 ℃.
preheater
helps start genset in low temperature.
If you don’t have specific needs for a controller brand, we would make our recommendations.
controller brand
to control all functions of genset.
You should choose this option if you need more convenient output for a genset below 30kw.
sockets
make genset output more convenient.
If you need to use genset for more than 8 hours a day, you should choose to increase the fuel tank of genset.
larger fuel tank
increase genset’s one-time use time.
If you require more convenient use of the fuel tank, you should choose this option.
separate fuel tank
replaces the bottom fuel tank and is more convenient to use
If the fuel you are using is not of good enough quality, you should choose this option.
fuel-water-separator
remove moisture from fuel and extend engine life
factory
overview
how we test the diesel gensets
We always get genuine and original engines from regular channels.
purchase engine
We always use the most sophisticated cutting instruments to cut sheet metal.
sheet metal cutting
The welding workers have 20+ years of experience and the welding points are flawless.
welding
Professional spray and baking booths are used to color the silent covers.
spray paint
Paste sound insulation cotton with a thickness greater than 3cm on the silent cover.
paste silent cotton
BISON brand brushless AC alternator is made by ourselves
alternator assembly
Connect engine and alternator.
semi finished genset
Establish a connection between the line and the controller.
install controller
Check whether the internal wiring is intact and working.
wiring
Assembling the silent cover after cutting and painting.
soundproof producing
Every genset would be tested in the testing center.
test center
Every genset would be tested for more than 30 minutes.
genset testing
Stick BISON or OEM logo lable.
stick logo
Packed with pearl cotton and stretch film.
packing
Loading is carried out by experienced forklift workers to ensure that every machine is in good condition.
loading
