home – power generator – industrial heavy duty 4-Stroke diesel generator
model: BS9500DSE
industrial heavy duty 4-stroke diesel generator
within 25 days delivery time after receiving the deposit！
Industrial heavy duty 4-stroke diesel generator from BISON diesel generator factory – max power 8.5 kw, single phase/three phase options,10 hours run time.
Experience the power and reliability of BISON’s industrial heavy-duty 4-stroke diesel generator. Ideal for construction sites, industrial facilities and emergency backup, the BS8500DSE guarantees a seamless power supply, backed by the reliability and efficiency of modern diesel technology.
features
Main features of industrial heavy duty generator
High performance: The BS9500DSE is rated at 8.0 kw with a peak output of 8.5 kw, ensuring consistent power for all your operating needs.
Flexible voltage and phase options: Choose between single-phase and three-phase configurations to meet your specific requirements. AC voltage can be customized to your country’s standards.
High-efficiency engine: Adopts BS1100FA 1-cylinder, 4-stroke, air-cooled engine with a displacement of 667 cc. Run at 3000 RPM (50 Hz) or 3600 RPM (60 Hz) for best performance.
Extended runtime: This 4-Stroke diesel generator has a 30-liter fuel tank capacity and can run continuously for up to 10 hours, minimizing the need for frequent refueling.
Electric start: Equipped with 36AH battery, electric start is easy and reliable, ensuring worry-free operation every time.
Durable construction: Made with BISON’s 100% copper-wound alternator, known for superior conductivity and durability.
Compact and portable: Despite its powerful performance, the size of this industrial heavy duty generator is easy to manage, with a carton size of 1120×660×860mm and a net weight of 210kgs, making it easy to transport and store.
specifications
| output | |
|---|---|
| rated power | 8.0 KW |
| maximum power | 8.5 KW |
| Phase | single-phase / three-phases (optional) |
| AC voltage | depends on your country’s voltage |
| single-phase AC amperage | running power ÷ using voltage |
| three-phase AC amperage | running power ÷ using voltage ÷ 1.3856 |
| frequency | 50 / 60 HZ |
| continuous operating time | 10 h |
| engine & emission | |
|---|---|
| engine type | 4-stroke, OHV, air-cooled |
| engine model name | BS168F-1 |
| bore × stroke | 68 × 45 MM |
| engine displacement | 196 CC |
| engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| recoil start | yes |
| electric start | optional |
| alternator | |
|---|---|
| winding material | 100% copper winding |
| power factor | 1.0 (single-phase) / 0.8 (three-phase) |
| fuel system | |
|---|---|
| fuel tank capacity | 15 l |
| oil capacity | 0.6 l |
| packaging | |
|---|---|
| carton dimensions (no wheels & handles) | 605 × 440 × 440 MM |
| generator net weight | 35 KGS |
| carton gross weight | 37 KGS |
optional
If your customers have remote start requirements, you should choose this option.
remote start
easy to move the generator
The customers who have high-end pursue of generator should choose this option.
digital display
easy to monitor the generator
The generators above 7 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
If the winter temperature in your area is below 0 ℃, you should choose this option.
glow plug
help to start in low temperature
factory
overview
how we test the gasoline generator
Improve the lift of the camshaft, determine the trajectory curve, and better analyze the state of the fuel injection pump and fuel injector.
camshaft test
Ensure that the gas tightness of the cylinder head meets the requirements and improves the performance stability of the generator.
cylinder head test
The oil central processor, all oil must be filtered and then used, reducing the wear of the parts.
oil quality testing
Make sure that all data indicators of the cylinder are normal and can meet the assembly requirements of the engine.
cylinder test
Crankcase has a oil leakage test to ensure that there is no oil leakage problem.
crankcase seal test
Ensure bearing sealing and no oil leakage
bearing seal test
Makes the surface of spare parts smoother and reduces wear.
honing parts
Correct the axis offset, skew, and other defects of the processed hole to ensure the position accuracy of the hole, while also obtaining the required hole diameter tolerance and surface roughness.
precision boring process
Make sure the connection between the cylinder head and the box is firm and there is no possibility of air or water leakage.
torque test
Make sure the engine is running normally and stably without any abnormal noise.
engine test
After the engine test, clean the internal residue to reduce the damage of the parts.
residue cleaning
Ensure the sealing of alternator is stable.
alternator air gap
After the alternator supplier’s first test, we would test it ourselves again to ensure alternator don’t have quality problem.
alternator 100% test
Make sure the generator can operate properly in low temperature conditions.
low temperature test
Well-packaged and ensure the safety of the generator.
packaging
support
warranty
※ Our commitment:
Dear customer, many thanks for considering our generator. We have firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every generator you own is rigorously tested and carefully manufactured!
※ Warranty time: 1 year after B/L date.
※ Warranty coverage: Non-human factors, the damage caused by machine its own quality problems.
※ How we fulfill our warranty:
Situation 1 Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.
Situation 2 Quality problem with small batches withnin warranty time: You give your customer a new generator for free→We would give you a discount in your next order corresponding to the amount of the severely damaged generator.
Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new generator for free firstly→We would send technicians to your country to repair these machines for you free of charge.
Situation 4 Quality problem with big batches if you buy your own brand within warranty time: You give your customer a new generator for free firstly→We would compensate you in batches in future orders.
OEM service
※ Design team size: 10 designers.
※ What can we design for you: sticker, carton, logo, poster…
※ Design time required after receving your deposit
Sticker design: within 2 days
Carton design: within 2 days
Logo: within 1 day
Poster: within 1 week
……
agent service
※ How to become a BISON agent: achieve orders of more than USD 1 million of BISON brand products in one year.
※ What can you get after becoming an agent:
We will assist you in building a BISON supermarket store locally
Give you free display racks and display cabinets
Provide you with free decoration design services.
……
※ At the same time, enjoy the supreme VIP warranty experience and service!
customs services
※ We can find the cheapest sea shipping price for you.
※ We can find a local customs clearance agent for you.
※ In some special cases, we can save you import tariff costs.
