homepower generator – household recoil start petrol generator
/
model: BS3500SM
certificates:
tüv rheinland
ce
rohs compliant
epa

household recoil start petrol generator

3000 watts
gasoline
home backup
1 year warranty

within 25 days delivery time after receiving the deposit!

moq
BISON brand
20 SETS
OEM sticker
50 SETS
OEM carton
100 SETS

BISON is a well-known gasoline generator manufacturer in the industry, recognized for delivering best-in-class generators that meet the highest quality and performance standards. With the BS3500SM household recoil start petrol generator, you can rely on the durability, reliability and longevity of your power source.

Recoil start for fast and easy operation: The BISON Home Recoil Start Gasoline Generator features a convenient recoil starting mechanism that makes starting the generator easy and hassle-free. With a simple pull, your generator is up and running.

Reliable gasoline power: As a gasoline generator, the BISON home recoil starter generator provides a reliable and readily available source of fuel. Gasoline is widely available, making this generator a practical choice for a variety of locations. Let you enjoy an uninterrupted power supply.

CCompact portable design: The BS3500SM home recoil start gasoline generator’s compact and portable design ensures easy transportation and storage. Whether you need power at home, during outdoor activities, or on the go, this generator has the flexibility to meet your energy needs.

features

household-recoil-start-petrol-generator-detail

legendary performance

As a leading professional petrol generator manufacturer and supplier in China, BISON provides you with reliable and efficient solutions to meet your household needs.

The recoil drive mechanism is built to last, providing long-lasting performance.

Easy to handle and store, perfect for daily use at home.

always use the Original spare parts​

Partner with BISON, a leading petrol generator manufacturer in China, and enhance your business with our quality products.

A reliable partner! Support your business with BISON’s commitment to quality and support.

BISON petrol generator’s CAMSHFT is made of PA66 material, it can perform mechanical reciprocating motion with a load of 100N at 900 times/min.

household-recoil-start-petrol-generator-2

specifications

output
rated power 2.8 KW
maximum power 3.0 KW
Phase single-phase / three-phases (optional)
AC voltage depends on your country’s voltage
single-phase AC amperage running power ÷ using voltage
three-phase AC amperage running power ÷ using voltage ÷ 1.3856
frequency 50 / 60 HZ
runtime-100% load 14.5 h
continuous operating time 10 h
engine & emission
engine type 4-stroke, OHV, air-cooled
engine model name BS170F
bore × stroke 70 × 56 MM
engine displacement 210 CC
engine speed 3000(50 Hz) / 3600(60 Hz) RPM
recoil start yes
electric start optional
alternator
winding material 100% copper winding
power factor 1.0 (single-phase) / 0.8 (three-phase)
fuel system
fuel tank capacity 15 l
oil capacity 0.6 l
packaging
carton dimensions (no wheels & handles) 605 × 440 × 440 MM
generator net weight 39 KGS
carton gross weight 41 KGS

optional

wheels-&-handles

The open frame type gasoline generators above 5 kilowatts should choose this option.

wheels & handles

easy to move the generator

electric-&-remote-start

The open frame type gasoline generators above 5 kilowatts should choose this option.

electric & remote start

easy to start the generator

digital-display

The customers who have high-end pursue of generator should choose this option.

digital display

easy to monitor the generator

industrial-socket

The generators above 7 kilowatts or have three-phase voltage should choose this option.

industrial socket

power for industrial use

ats

When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.

ATS

automatically start without human intervention required

factory

overview

how we test the gasoline generator

flywheel clearance

Ensure the engine better store energy and inertia.

flywheel clearance

power debugging

Ensure the alternator could output current stably.

power debugging

fuel tank airtight

Ensure the stability and sealing of the fuel tank.

fuel tank airtight

motor air gap

Ensure the sealing of alternator is stable.

alternator air gap

cylinder head seal

Ensure the sealing of cylinder head is intact.

cylinder head seal

connecting rod torque

Ensure a stable connection between the connecting rod and crankshaft.

connecting rod torque

cylinder head torque

Ensure the cylinder head connection is stable.

cylinder head torque

box torque

Ensure the crankcase torque is correct and the same for each engine.

crankcase torque

air tightness test

Ensure the sealing of the engine is stable.

air tightness test

muffler tightening torque

Ensure the muffler connection is stable.

muffler tightening torque

comprehensive performance test

Ensure stable performance and output of the generator.

comprehensive performance test

pressure testing

Ensure the voltage of generator is stable.

voltage test

appearance final inspection

Ensure the generator has no cosmetic defects.

appearance final inspection

weighing check

Ensure we don’t miss any accessories in the carton.

weighing check

delivery-3

Well-packaged and ensure the safety of the generator.

packaging

support

warranty

※  Our commitment:

Dear customer, many thanks for considering our generator. We have firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every generator you own is rigorously tested and carefully manufactured!

※  Warranty time: 1 year after B/L date.

※  Warranty coverage: Non-human factors, the damage caused by machine its own quality problems.

※  How we fulfill our warranty:

Situation 1  Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.

Situation 2  Quality problem with small batches withnin warranty time: You give your customer a new generator for free→We would give you a discount in your next order corresponding to the amount of the severely damaged generator.

Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new generator for free firstly→We would send technicians to your country to repair these machines for you free of charge.

Situation 4 Quality problem with big batches if you buy your own brand within warranty time: You give your customer a new generator for free firstly→We would compensate you in batches in future orders.

OEM Service

※  Design team size: 10 designers.

※  What can we design for you: sticker, carton, logo, poster…

※  Design time required after receving your deposit

Sticker desgin: within 2 days

Carton desgin: within 2 days

Logo: within 1 day

Poster: within 1 week

……
