remote start three phase gasoline generator
within 25 days delivery time after receiving the deposit！
BS7500SM is a professional-grade gasoline generator ideal for a variety of applications including construction, manufacturing and events. It features a powerful four-stroke, OHV, air-cooled engine that delivers 6.5 kw of maximum power and can run for up to 8 hours on a single tank of fuel.
features
ac and dc output
The BS7500SM remote start three-phase generator provides both AC and DC outputs so you can power a variety of equipment including lights, appliances and tools. The AC output is 220 volts and the DC output is 12 volts.
remote start and recoil start
The BS7500SM 6.5kw three phase gasoline generator features both remote start and recoil start for added convenience and flexibility. Remote start allows you to start the generator from up to 30 metres away, while recoil start is ideal for when you need to start the generator manually.
Efficient
Efficient bs190f 4-stroke ohv engine with 420 cc displacement, paired with a high-quality alternator featuring 100% copper winding. This minimizes interruptions and enhances productivity in demanding work environments.
portable design
With compact dimensions of 755 × 570 × 605 mm and a manageable weight of 83 kg, this generator strikes an ideal balance between performance and mobility. Its portability makes it well-suited for various on-site applications, allowing users to easily transport and position the generator wherever power is needed.
specifications
| output | |
|---|---|
| rated power | 6.0 KW |
| maximum power | 6.5 KW |
| Phase | single-phase / three-phases (optional) |
| AC voltage | depends on your country’s voltage |
| single-phase AC amperage | running power ÷ using voltage |
| three-phase AC amperage | running power ÷ using voltage ÷ 1.3856 |
| frequency | 50 / 60 HZ |
| continuous operating time | 8 h |
| engine & emission | |
|---|---|
| engine type | 4-stroke, OHV, air-cooled |
| engine model name | BS190F |
| bore × stroke | 90 × 66 MM |
| engine displacement | 420 CC |
| engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| recoil start | yes |
| electric start | optional |
| alternator | |
|---|---|
| winding material | 100% copper winding |
| power factor | 1.0 (single-phase) / 0.8 (three-phase) |
| fuel system | |
|---|---|
| fuel tank capacity | 25 l |
| oil capacity | 1.1 l |
| packaging | |
|---|---|
| carton dimensions (no wheels & handles) | 755 × 570 × 605 MM |
| generator net weight | 83 KGS |
| carton gross weight | 90 KGS |
optional
The open frame type gasoline generators above 5 kilowatts should choose this option.
wheels & handles
easy to move the generator
The open frame type gasoline generators above 5 kilowatts should choose this option.
electric & remote start
easy to start the generator
The customers who have high-end pursue of generator should choose this option.
digital display
easy to monitor the generator
The generators above 7 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
factory
overview
how we test the gasoline generator
Ensure the engine better store energy and inertia.
flywheel clearance
Ensure the alternator could output current stably.
power debugging
Ensure the stability and sealing of the fuel tank.
fuel tank airtight
Ensure the sealing of alternator is stable.
alternator air gap
Ensure the sealing of cylinder head is intact.
cylinder head seal
Ensure a stable connection between the connecting rod and crankshaft.
connecting rod torque
Ensure the cylinder head connection is stable.
cylinder head torque
Ensure the crankcase torque is correct and the same for each engine.
crankcase torque
Ensure the sealing of the engine is stable.
air tightness test
Ensure the muffler connection is stable.
muffler tightening torque
Ensure stable performance and output of the generator.
comprehensive performance test
Ensure the voltage of generator is stable.
voltage test
Ensure the generator has no cosmetic defects.
appearance final inspection
Ensure we don’t miss any accessories in the carton.
weighing check
Well-packaged and ensure the safety of the generator.
packaging
support
agent service
※How to become a BISON agent: achieve orders of more than USD 1 million of BISON brand products in one year.
※What can you get after becoming an agent:
We will assist you in building a BISON supermarket store locally
Give you free display racks and display cabinets
Provide you with free decoration design services.
……
※At the same time, enjoy the supreme VIP warranty experience and service!
customs services
※ We can find the cheapest sea shipping price for you.
※ We can find a local customs clearance agent for you.
※ In some special cases, we can save you import tariff costs.
By choosing BISON, you’ll gain access to top-quality products, along with exceptional support and innovative solutions tailored to your specific business needs. Whether you’re looking to expand your offerings or need a dependable power source for your own operations, BISON is the perfect choice to drive your success.
