home – power generator – superior quality 5.5kw portable diesel generators
model: BS6500DCE
superior quality 5.5kw portable diesel generators
within 25 days delivery time after receiving the deposit！
BISON’s superior quality portable generators are tailor-made to meet the needs of various international markets and are available in single-phase and three-phase models, ensuring they adapt to different electrical standards around the world. The portable diesel generator can exert a maximum output power of 5.5kw and provide a stable rated power of 5.0kw, easily handling heavy loads.
After BISON’s optimized design, superior quality 5.5kw generators have a compact structure and can be easily deployed in various environments. While the unit doesn’t include wheels, BS6500DCE’s lightweight and manageable size ensures it can still be positioned and set up easily.
Come and experience the durability of the BISON BS6500DCE generator integrated with its advanced technology. Operating smoothly at 3000 RPM for 50 Hz and 3600 RPM for 60 Hz, this portable diesel generators maintain efficiency without compromising power or performance. You will also appreciate the 12.5L fuel capacity, allowing up to 6.5 hours of running time and reducing the frequency of refueling.
features
Excellent design of 5.5kw generators
BISON is an influential generator factory factory, BS6500DCE provides a maximum output of 5.5kW, providing sufficient power for electrical appliances.
Use high quality spare parts
Invest in peace of mind with the BISON 5.5kW portable diesel generator. We use only the highest-quality components to ensure exceptional performance and durability.
All BS6500DCE components are made of high-quality materials, such as 100% copper windings, which provide better conductivity, heat resistance and service life.
BISON diesel generator factory are typically certified by relevant quality and safety regulators, which may include ISO standards for quality management systems, CE marking for European safety standards, EPA or CARB certification for US emissions controls
specifications
| output | |
|---|---|
| rated power | 5.0 KW |
| maximum power | 5.5 KW |
| Phase | single-phase / three-phases (optional) |
| AC voltage | depends on your country’s voltage |
| single-phase AC amperage | running power ÷ using voltage |
| three-phase AC amperage | running power ÷ using voltage ÷ 1.3856 |
| frequency | 50 / 60 HZ |
| continuous operating time | 6.5 h |
| engine & emission | |
|---|---|
| engine type | 4-stroke, OHV, air-cooled |
| engine model name | BS168F-1 |
| bore × stroke | 68 × 45 MM |
| engine displacement | 196 CC |
| engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| recoil start | yes |
| electric start | optional |
| alternator | |
|---|---|
| winding material | 100% copper winding |
| power factor | 1.0 (single-phase) / 0.8 (three-phase) |
| fuel system | |
|---|---|
| fuel tank capacity | 15 l |
| oil capacity | 0.6 l |
| packaging | |
|---|---|
| carton dimensions (no wheels & handles) | 605 × 440 × 440 MM |
| generator net weight | 35 KGS |
| carton gross weight | 37 KGS |
optional
The open frame type gasoline generators above 5 kilowatts should choose this option.
electric & remote start
easy to start the generator
The customers who have high-end pursue of generator should choose this option.
digital display
easy to monitor the generator
The generators above 7 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
If the winter temperature in your area is below 0 ℃, you should choose this option.
glow plug
help to start in low temperature
factory
overview
how we test the gasoline generator
Improve the lift of the camshaft, determine the trajectory curve, and better analyze the state of the fuel injection pump and fuel injector.
camshaft test
Ensure that the gas tightness of the cylinder head meets the requirements and improves the performance stability of the generator.
cylinder head test
The oil central processor, all oil must be filtered and then used, reducing the wear of the parts.
oil quality testing
Make sure that all data indicators of the cylinder are normal and can meet the assembly requirements of the engine.
cylinder test
Crankcase has a oil leakage test to ensure that there is no oil leakage problem.
crankcase seal test
Ensure bearing sealing and no oil leakage
bearing seal test
Makes the surface of spare parts smoother and reduces wear.
honing parts
Correct the axis offset, skew, and other defects of the processed hole to ensure the position accuracy of the hole, while also obtaining the required hole diameter tolerance and surface roughness.
precision boring process
Make sure the connection between the cylinder head and the box is firm and there is no possibility of air or water leakage.
torque test
Make sure the engine is running normally and stably without any abnormal noise.
engine test
After the engine test, clean the internal residue to reduce the damage of the parts.
residue cleaning
Ensure the sealing of alternator is stable.
alternator air gap
After the alternator supplier’s first test, we would test it ourselves again to ensure alternator don’t have quality problem.
alternator 100% test
Make sure the generator can operate properly in low temperature conditions.
low temperature test
Well-packaged and ensure the safety of the generator.
packaging
