super silent type 100kva genset for hospital use
As your trusted genset partner for generations, BISON ensures that every product we deliver is of unrivalled quality, reliability and performance. Invest in the BS-FS100 and elevate your hospital’s power infrastructure to a level of unrivalled excellence. Join us in powering a healthier tomorrow.
The FAWDE BS-FS100 is a super silent type 100kVA genset designed specifically for hospital environments, bringing you top-notch power reliability. Crafted by BISON’s expert engineers, it combines unrivalled performance with silent operation to ensure an uninterrupted power supply without disrupting the therapeutic environment of the medical facility.
features
turbocharged for optimal performance
The 100kva diesel genset used in the hospital is equipped with a high-performance engine model CA6DF2D-14D with turbocharged air intake for improved power efficiency and reliability. This water-cooled, in-line, four-stroke, direct-injection engine with six cylinders and a displacement of 6.56 litres ensures seamless operation even during peak demand periods.
Managing the BS-FS100 is easy with the SMARTGEN HGM6120 controller.This advanced system provides comprehensive monitoring and control to ensure optimal performance and proactive maintenance.
With a voltage regulation range of ≤ ±1%, this alternator ensures stable power output and protects sensitive school equipment from voltage fluctuations. Intelligent controller for smart management:
quiet confidence for hospitals
The FADEW 100kva genset is a premium quality ultra-quiet genset designed to meet the demanding needs of hospitals. This powerful 80 kW / 100 kVA 50 Hz genset offers excellent performance and extremely low noise levels to ensure a quiet environment for patients and staff. Ultra-quiet operation:
80 kW mains/100 kVA standby power supports essential hospital equipment in the event of a power failure, ensuring continuity of care.
Brushless alternator for superior efficiency, durability and low maintenance requirements.
specifications
| output | |
|---|---|
| rated power | 80 KW / 100 KVA |
| voltage | 220 V / 380 V |
| frequency | 50 HZ |
| Phase / Wire | 3 Phase / 4 Wire |
| Power Factor | 0.8 |
| engine & emission | |
|---|---|
| engine type | CA6DF2D-14D |
| type | Water-cooled, inline, 4-stroke, direct injection |
| prime power | 96 KW |
| intake type | Turbocharged |
| no.cylinders | 6 |
| bore × stroke | 110 × 115 MM |
| displacement | 6.56 L |
| 100% prime power fuel consumption | 19.1 L/H |
| alternator | |
|---|---|
| brand model | BS274C |
| prime power | 80 KW / 100 KVA |
| power efficiency | 88.50% |
| voltage regulation | ≤ ±1 |
| excitation type | brushless |
| insulation class | h |
| controller | |
|---|---|
| band | SMARTGEN |
| model | HGM6120 |
| packaging | |
|---|---|
| dimension | 2300 × 850 × 1550 MM |
| weight | 1250 KGS |
optional
When you take genset as backup power, you could choose this.
ATS
automatically start without human intervention required.
You should choose this option when the lowest temperature of the year in which the gensets are used is below 0 ℃.
preheater
helps start genset in low temperature.
If you don’t have specific needs for a controller brand, we would make our recommendations.
controller brand
to control all functions of genset.
You should choose this option if you need more convenient output for a genset below 30kw.
sockets
make genset output more convenient.
If you need to use genset for more than 8 hours a day, you should choose to increase the fuel tank of genset.
larger fuel tank
increase genset’s one-time use time.
If you require more convenient use of the fuel tank, you should choose this option.
separate fuel tank
replaces the bottom fuel tank and is more convenient to use
If the fuel you are using is not of good enough quality, you should choose this option.
fuel-water-separator
remove moisture from fuel and extend engine life
factory
overview
how we test the diesel gensets
We always get genuine and original engines from regular channels.
purchase engine
We always use the most sophisticated cutting instruments to cut sheet metal.
sheet metal cutting
The welding workers have 20+ years of experience and the welding points are flawless.
welding
Professional spray and baking booths are used to color the silent covers.
spray paint
Paste sound insulation cotton with a thickness greater than 3cm on the silent cover.
paste silent cotton
BISON brand brushless AC alternator is made by ourselves
alternator assembly
Connect engine and alternator.
semi finished genset
Establish a connection between the line and the controller.
install controller
Check whether the internal wiring is intact and working.
wiring
Assembling the silent cover after cutting and painting.
soundproof producing
Every genset would be tested in the testing center.
test center
Every genset would be tested for more than 30 minutes.
genset testing
Stick BISON or OEM logo lable.
stick logo
Packed with pearl cotton and stretch film.
packing
Loading is carried out by experienced forklift workers to ensure that every machine is in good condition.
loading
support
warranty
※ Our commitment:
Dear customer, many thanks for considering our generator. We have firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every generator you own is rigorously tested and carefully manufactured!
※ Warranty time: 2 year after B/L date.
※ Warranty coverage: Non-human factors, the damage caused by machine its own quality problems.
※ How we fulfill our warranty:
Situation 1 Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.
Situation 2 Quality problem with small batches withnin warranty time: You give your customer a new generator for free→We would give you a discount in your next order corresponding to the amount of the severely damaged generator.
Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new generator for free firstly→We would send technicians to your country to repair these machines for you free of charge.
Situation 4 Quality problem with big batches if you buy your own brand within warranty time: You give your customer a new generator for free firstly→We would compensate you in batches in future orders.
OEM Service
※ Design team size: 10 designers.
※ What can we design for you: sticker, carton, logo, poster…
※ Design time required after receving your deposit
Sticker desgin: within 2 days
Carton desgin: within 2 days
Logo: within 1 day
Poster: within 1 week
……
