powered by 240kw 300kva brushless water-cooled diesel genset
powered by 240kw 300kva brushless water-cooled diesel genset is designed for commercial applications to provide reliable backup power for hotels.
BS-YS300: Your Ultimate Power Solution
As a professional YUCHAI genset supplier based in China, we are proud to introduce the BS-YS300, a genset that promises to exceed your expectations with unrivalled performance and reliability. A genset that will revolutionise your power solutions.
features
The YUCHAI brushless water-cooled diesel genset boasts unrivalled efficiency and power: the brushless alternator minimises maintenance requirements and extends generator life. Efficient water cooling system ensures reliable performance even in hot and harsh environments.
- Optimised for 50 Hz operation: ensuring compatibility with most grids in South East Asia and beyond.
- Delivering a powerful 300kVA/240kW of power: Handles demanding electrical loads with ease.
The BS-YS300 is the ideal choice for dealers who want to provide their customers with a quality, reliable and efficient backup power solution. Offering powered by 240kw 300kva diesel genset meets the needs of businesses looking for a reliable and powerful backup power solution.
Other advantages for dealers:
- Low noise operation: makes the generator set suitable for urban environments.
- Automatic Voltage Regulation (AVR): Ensures constant and stable power output.
- Various optional features: Can be customised to meet specific needs (e.g. acoustic enclosure, remote start).
- Reliable after-sales support: Provides customers with peace of mind.
specifications
| output | |
|---|---|
| rated power | 240 KW / 300 KVA |
| voltage | 220 V / 380 V |
| frequency | 50 HZ |
| Phase / Wire | 3 Phase / 4 Wire |
| Power Factor | 0.8 |
| engine & emission | |
|---|---|
| engine type | 1506A-E88TAG5 |
| type | Water-cooled, inline, 4-stroke, direct injection |
| prime power | 267 KW |
| intake type | Turbocharged aftercooled |
| no.cylinders | 6 |
| bore × stroke | 112 × 149 MM |
| displacement | 8.8 l |
| 100% prime power fuel consumption | 65 L/H |
| alternator | |
|---|---|
| brand model | HCI444D |
| prime power | 240 KW / 300 KVA |
| power efficiency | 88.50% |
| voltage regulation | ≤ ±1 |
| excitation type | brushless |
| insulation class | h |
| controller | |
|---|---|
| band | deepsea |
| model | DSE7320 |
| packaging | |
|---|---|
| dimension | 3950 × 1400 × 2000 MM |
| weight | 2500 KGS |
optional
When you take genset as backup power, you could choose this.
ATS
automatically start without human intervention required.
You should choose this option when the lowest temperature of the year in which the gensets are used is below 0 ℃.
preheater
helps start genset in low temperature.
If you don’t have specific needs for a controller brand, we would make our recommendations.
controller brand
to control all functions of genset.
You should choose this option if you need more convenient output for a genset below 30kw.
sockets
make genset output more convenient.
If you need to use genset for more than 8 hours a day, you should choose to increase the fuel tank of genset.
larger fuel tank
increase genset’s one-time use time.
If you require more convenient use of the fuel tank, you should choose this option.
separate fuel tank
replaces the bottom fuel tank and is more convenient to use
If the fuel you are using is not of good enough quality, you should choose this option.
fuel-water-separator
remove moisture from fuel and extend engine life
factory
overview
how we test the diesel gensets
We always get genuine and original engines from regular channels.
purchase engine
We always use the most sophisticated cutting instruments to cut sheet metal.
sheet metal cutting
The welding workers have 20+ years of experience and the welding points are flawless.
welding
Professional spray and baking booths are used to color the silent covers.
spray paint
Paste sound insulation cotton with a thickness greater than 3cm on the silent cover.
paste silent cotton
BISON brand brushless AC alternator is made by ourselves
alternator assembly
Connect engine and alternator.
semi finished genset
Establish a connection between the line and the controller.
install controller
Check whether the internal wiring is intact and working.
wiring
Assembling the silent cover after cutting and painting.
soundproof producing
Every genset would be tested in the testing center.
test center
Every genset would be tested for more than 30 minutes.
genset testing
Stick BISON or OEM logo lable.
stick logo
Packed with pearl cotton and stretch film.
packing
Loading is carried out by experienced forklift workers to ensure that every machine is in good condition.
loading
support
warranty
※ Our commitment:
Dear customer, many thanks for considering our generator. We have firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every generator you own is rigorously tested and carefully manufactured!
※ Warranty time: 2 year after B/L date.
※ Warranty coverage: Non-human factors, the damage caused by machine its own quality problems.
※ How we fulfill our warranty:
Situation 1 Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.
Situation 2 Quality problem with small batches withnin warranty time: You give your customer a new generator for free→We would give you a discount in your next order corresponding to the amount of the severely damaged generator.
Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new generator for free firstly→We would send technicians to your country to repair these machines for you free of charge.
Situation 4 Quality problem with big batches if you buy your own brand within warranty time: You give your customer a new generator for free firstly→We would compensate you in batches in future orders.
OEM Service
※ Design team size: 10 designers.
※ What can we design for you: sticker, carton, logo, poster…
※ Design time required after receving your deposit
Sticker desgin: within 2 days
Carton desgin: within 2 days
Logo: within 1 day
Poster: within 1 week
……
