model: BS2800H
2800w 4-stroke gasoline power generator
within 25 days delivery time after receiving the deposit！
The BISON 2800w 4-stroke gasoline power generator is a professional-grade gasoline generator ideal for a variety of applications including construction and home backup power. With its powerful four-stroke engine and rated output of 2800W, the BS2800H can reliably power the most demanding tasks.
Smooth output: The alternator of 4-stroke gasoline power generator ensures stable voltage output, staying within 230V +/- 3%. Additionally, the BS2800H gasoline generator is rugged and can effectively withstand the harsh conditions of power tools and construction site equipment.
Sockets: BISON 4-stroke gasoline generator features two 16 amp sockets to power a variety of devices. The sockets can be adapted to your country’s specifications, such as US and Australian socket options.
High-quality power: BISON’s proprietary four-stroke engine is 15% more fuel efficient than standard generators while reducing emissions by 30%.
User-friendly features:
- Low oil alert system
- Overload protection
- Automatic voltage regulation
- Two 120V AC outlets
- One DC outlet
features
legendary performance
2800w peak power has the advantage of long-term operation without power decay. Zero-delay power output responds to load changes within milliseconds. Therefore, the 2800w 4-stroke generator can be used in the following scenarios:
- Keep basic appliances, such as refrigerators, freezers, lighting, and heating and cooling systems, running during power outages.
- Provide equipment operation power for construction, renovation, and DIY projects in areas without electricity.
- Provide reliable power for RV appliances, lighting, and entertainment systems.
- Power livestock drinking systems, feed equipment, and barn lighting.
Always provide high quality
As a leading gasoline generator manufacturer in China, we conduct rigorous quality inspections and performance tests on each generator. BISON 4-stroke gasoline generator can successfully start large motors up to 1hp without voltage drops or stalls.
Say goodbye to complex installations with recoil-activated design, allowing you to focus on what matters most
Our generator’s camshaft is made of PA66 material, it can perform mechanical reciprocating motion with a load of 100N at 900 times/min.
specifications
| output | |
|---|---|
| rated power | 2.5 KW |
| maximum power | 2.8 KW |
| Phase | single-phase / three-phases (optional) |
| AC voltage | depends on your country’s voltage |
| single-phase AC amperage | running power ÷ using voltage |
| three-phase AC amperage | running power ÷ using voltage ÷ 1.3856 |
| frequency | 50 / 60 HZ |
| continuous operating time | 13 h |
| engine & emission | |
|---|---|
| engine type | 4-stroke, OHV, air-cooled |
| engine model name | BS168F-1 |
| bore × stroke | 68 × 45 MM |
| engine displacement | 196 CC |
| engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| recoil start | yes |
| electric start | optional |
| alternator | |
|---|---|
| winding material | 100% copper winding |
| power factor | 1.0 (single-phase) / 0.8 (three-phase) |
| fuel system | |
|---|---|
| fuel tank capacity | 15 l |
| oil capacity | 0.6 l |
| packaging | |
|---|---|
| carton dimensions (no wheels & handles) | 605 × 440 × 440 MM |
| generator net weight | 35 KGS |
| carton gross weight | 37 KGS |
optional
The open frame type gasoline generators above 5 kilowatts should choose this option.
wheels & handles
easy to move the generator
The open frame type gasoline generators above 5 kilowatts should choose this option.
electric & remote start
easy to start the generator
The customers who have high-end pursue of generator should choose this option.
digital display
easy to monitor the generator
The generators above 7 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
factory
overview
how we test the gasoline generator
Ensure the engine better store energy and inertia.
flywheel clearance
Ensure the alternator could output current stably.
power debugging
Ensure the stability and sealing of the fuel tank.
fuel tank airtight
Ensure the sealing of alternator is stable.
alternator air gap
Ensure the sealing of cylinder head is intact.
cylinder head seal
Ensure a stable connection between the connecting rod and crankshaft.
connecting rod torque
Ensure the cylinder head connection is stable.
cylinder head torque
Ensure the crankcase torque is correct and the same for each engine.
crankcase torque
Ensure the sealing of the engine is stable.
air tightness test
Ensure the muffler connection is stable.
muffler tightening torque
Ensure stable performance and output of the generator.
comprehensive performance test
Ensure the voltage of generator is stable.
voltage test
Ensure the generator has no cosmetic defects.
appearance final inspection
Ensure we don’t miss any accessories in the carton.
weighing check
Well-packaged and ensure the safety of the generator.
packaging
support
warranty
※ Our commitment:
Dear customer, many thanks for considering our generator. We have firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every generator you own is rigorously tested and carefully manufactured!
※ Warranty time: 1 year after B/L date.
※ Warranty coverage: Non-human factors, the damage caused by machine its own quality problems.
※ How we fulfill our warranty:
Situation 1 Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.
Situation 2 Quality problem with small batches within warranty time: You give your customer a new generator for free→We would give you a discount in your next order corresponding to the amount of the severely damaged generator.
Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new generator for free firstly→We would send technicians to your country to repair these machines for you free of charge.
Situation 4 Quality problem with big batches if you buy your own brand within warranty time: You give your customer a new generator for free firstly→We would compensate you in batches in future orders.
OEM Service
※ Design team size: 10 designers.
※ What can we design for you: sticker, carton, logo, poster…
※ Design time required after receiving your deposit
Sticker design: within 2 days
Carton design: within 2 days
Logo: within 1 day
Poster: within 1 week
……
