5kw ac 3 phase electric gasoline generator
within 25 days delivery time after receiving the deposit！
Are you still looking for a powerful and reliable solution for your power generation needs? BS6500H is a state-of-the-art 5kW AC 3-phase electric gasoline generator, BISON, a gasoline generator supplier is always striving for excellence in generators.
The 3-phase gasoline generator has an unmatched 5kW output to power workshops, construction sites, food trucks and even small homes. Handles heavy appliances, machinery and tools with ease.
Designed for versatility, the BISON generator supports a three-phase power supply that provides greater efficiency and balanced power distribution. This feature makes it an ideal choice for power tool applications
The electric start function of 5kw 3-phase gasoline generator provides more convenience for users. Simply press the button to start the generator, eliminating the hassle of pulling the start manually,.
The BISON 5kw 3-phase generator is powered by a precision-engineered, fuel-efficient gasoline engine that increases power output while reducing fuel consumption. This ensures that your use of the BISON generator is economically efficient.
features
legendary performance
We know what is the most attractive, let’s provide a powerful & elegant generator to your customer.
BISON gasoline generators have a highly efficient power transfer mechanism that reduces your generator’s average start-up time by 15% compared to the competition.
The 5kw ac 3 phase electric gasoline generator uses advanced engineering to minimize wear and tear and reduce maintenance costs by up to 25%, making it more cost effective for customers.
always use the Original spare parts
BISON gasoline generator supplier recoil starters are designed with innovative materials and technology to ensure durability.
BISON generator’s piston weight is 5% higher than fraternity, good for such as Oil Burning, Carbon Deposition, Piston Scuffing, and Insufficient Power.
Durability tests have shown that BISON recoil starters have a 20% longer life cycle than the industry standard.
specifications
| output | |
|---|---|
| rated power | 5.0 KW |
| maximum power | 5.5 KW |
| Phase | single-phase / three-phases (optional) |
| AC voltage | depends on your country’s voltage |
| single-phase AC amperage | running power ÷ using voltage |
| three-phase AC amperage | running power ÷ using voltage ÷ 1.3856 |
| frequency | 50 / 60 HZ |
| continuous operating time | 9.5 h |
| engine & emission | |
|---|---|
| engine type | 4-stroke, OHV, air-cooled |
| engine model name | BS190F |
| bore × stroke | 90 × 66 MM |
| engine displacement | 420 CC |
| engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| recoil start | yes |
| electric start | optional |
| alternator | |
|---|---|
| winding material | 100% copper winding |
| power factor | 1.0 (single-phase) / 0.8 (three-phase) |
| fuel system | |
|---|---|
| fuel tank capacity | 25 l |
| oil capacity | 1.1 l |
| packaging | |
|---|---|
| carton dimensions (no wheels & handles) | 690 × 530 × 555 MM |
| generator net weight | 75 KGS |
| carton gross weight | 82 KGS |
optional
The open frame type gasoline generators above 5 kilowatts should choose this option.
wheels & handles
easy to move the generator
The open frame type gasoline generators above 5 kilowatts should choose this option.
electric & remote start
easy to start the generator
The customers who have high-end pursue of generator should choose this option.
digital display
easy to monitor the generator
The generators above 7 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
factory
overview
how we test the gasoline generator
support
Ensure the engine better store energy and inertia.
flywheel clearance
Ensure the alternator could output current stably.
power debugging
Ensure the stability and sealing of the fuel tank.
fuel tank airtight
Ensure the sealing of alternator is stable.
alternator air gap
Ensure the sealing of cylinder head is intact.
cylinder head seal
Ensure a stable connection between the connecting rod and crankshaft.
connecting rod torque
Ensure the cylinder head connection is stable.
cylinder head torque
Ensure the crankcase torque is correct and the same for each engine.
crankcase torque
Ensure the sealing of the engine is stable.
air tightness test
Ensure the muffler connection is stable.
muffler tightening torque
Ensure stable performance and output of the generator.
comprehensive performance test
Ensure the voltage of generator is stable.
voltage test
Ensure the generator has no cosmetic defects.
appearance final inspection
Ensure we don’t miss any accessories in the carton.
weighing check
Well-packaged and ensure the safety of the generator.
packaging
warranty
※ Our commitment:
Dear customer, many thanks for considering our generator. BISON has firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every generator you own is rigorously tested and carefully manufactured!
※ Warranty time: 1 year after B/L date.
※ Warranty coverage: Non-human factors, the damage caused by the machine its quality problems.
※ How we fulfill our warranty:
Situation 1 Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.
Situation 2 Quality problem with small batches within warranty time: You give your customer a new generator for free→We will give you a discount in your next order corresponding to the amount of the severely damaged generator.
Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new generator for free firstly→We would send technicians to your country to repair these machines for you free of charge.
Situation 4 Quality problem with big batches if you buy your brand within warranty time: You give your customer a new generator for free firstly→We would compensate you in batches in future orders.
OEM Service
※ Design team size: 10 designers.
※ What can we design for you: sticker, carton, logo, poster…
※ Design time required after receiving your deposit
Sticker design: within 2 days
Carton design: within 2 days
Logo: within 1 day
Poster: within 1 week
……
