model: BS-IS38
ISUZU 38kva diesel genset with ce ISO
Premium ISUZU 38kVA genset with CE ISO certification
Built by ISUZU genset manufacturers, this CE and ISO certified 38kVA diesel genset is designed for demanding applications to unleash reliable, efficient power. It is the perfect power solution for dealers seeking to provide customers with unmatched performance and peace of mind.
Choose the BS-IS38 diesel genset with Ce ISO for a reliable, efficient, and durable power solution. Perfect for dealers seeking rugged, certified gensets with superior performance and minimal operating costs.
features
Powered by ISUZU, the 38kva diesel genset boasts the legendary durability of a water-cooled, four-stroke ISUZU four-cylinder engine (JE493ZLDB-02) to ensure long-lasting, reliable operation even in the harshest conditions.
With an output of 38 kVA, the genset with Ce ISO is powerful enough to run multiple devices simultaneously, making it ideally suited to support basic operations in the event of a power outage or as a primary power source for off-grid locations.
Designed for heavy-duty use, the ISUZU 38kva diesel genset features rugged construction and superior components to ensure maximum uptime and a longer lifespan.
Diesel gensets with Ce ISO and ISUZU engines, have a power generation efficiency of 88.50 per cent, optimising the amount of power generated and ensuring that every drop of fuel is worth its weight in gold.
It comes in a compact package with dimensions of 2100 × 900 × 1250 mm and a weight of 950 kg. Its portable design ensures easy transport and installation, making it ideal for a variety of field applications.
Used in conjunction with the SMARTGEN HGM6120 controller, it provides you with intelligent control and monitoring capabilities.
specifications
| output | |
|---|---|
| rated power | 30 KW / 38 KVA |
| voltage | 220 V / 380 V |
| frequency | 50 HZ |
| phase / wire | 3 phase / 4 wire |
| power factor | 1.0 |
| engine & emission | |
|---|---|
| engine model | JE493ZLDB-02 |
| engine type | water-cooled, inline, 4-stroke, direct injection |
| prime power | 38 KW |
| intake type | intercooling turbo |
| no.cylinders | 4 |
| bore × stroke | 93 × 102 MM |
| displacement | 2.771 l |
| 100% prime power fuel consumption | 8.9 L/H |
| alternator | |
|---|---|
| brand model | BS184H |
| prime power | 30 KW / 38 KVA |
| power efficiency | 88.50% |
| voltage regulation | ≤ ±1 |
| excitation type | brushless |
| insulation class | h |
| controller | |
|---|---|
| band | SMARTGEN |
| model | HGM6120 |
| packaging | |
|---|---|
| dimension | 2100 × 900 × 1250 MM |
| weight | 950 KGS |
optional
When you take genset as backup power, you could choose this.
ATS
automatically start without human intervention required.
You should choose this option when the lowest temperature of the year in which the gensets are used is below 0 ℃.
preheater
helps start genset in low temperature.
If you don’t have specific needs for a controller brand, we would make our recommendations.
controller brand
to control all functions of genset.
You should choose this option if you need more convenient output for a genset below 30kw.
sockets
make genset output more convenient.
If you need to use genset for more than 8 hours a day, you should choose to increase the fuel tank of genset.
larger fuel tank
increase genset’s one-time use time.
If you require more convenient use of the fuel tank, you should choose this option.
separate fuel tank
replaces the bottom fuel tank and is more convenient to use
If the fuel you are using is not of good enough quality, you should choose this option.
fuel-water-separator
remove moisture from fuel and extend engine life
factory
overview
how we test the diesel gensets
We always get genuine and original engines from regular channels.
purchase engine
We always use the most sophisticated cutting instruments to cut sheet metal.
sheet metal cutting
The welding workers have 20+ years of experience and the welding points are flawless.
welding
Professional spray and baking booths are used to color the silent covers.
spray paint
Paste sound insulation cotton with a thickness greater than 3cm on the silent cover.
paste silent cotton
BISON brand brushless AC alternator is made by ourselves
alternator assembly
Connect engine and alternator.
semi finished genset
Establish a connection between the line and the controller.
install controller
Check whether the internal wiring is intact and working.
wiring
Assembling the silent cover after cutting and painting.
soundproof producing
Every genset would be tested in the testing center.
test center
Every genset would be tested for more than 30 minutes.
genset testing
Stick BISON or OEM logo lable.
stick logo
Packed with pearl cotton and stretch film.
packing
Loading is carried out by experienced forklift workers to ensure that every machine is in good condition.
loading
support
warranty
※ Our commitment:
Dear customer, many thanks for considering our genset. We have firm confidence in the quality and performance of our products, so our warranty is more than just an oral promise or a document, it is our commitment to quality. We will work tirelessly to ensure that every genset you own is rigorously tested and carefully manufactured!
※ Warranty time: 2 year after B/L date.
※ Warranty coverage: Non-human factors, the damage caused by machine its own quality problems.
※ How we fulfill our warranty:
Situation 1 Conveniently replaceable spare parts are damaged within warranty time→We provide new spare parts free of charge and ship them with your next order.
Situation 2 Quality problem with small batches withnin warranty time: You give your customer a new genset for free→We would give you a discount in your next order corresponding to the amount of the severely damaged genset.
Situation 3 Quality problem with big batches if you buy Bison brand within warranty time: You give your customer a new genset for free firstly→We would send technicians to your country to repair these machines for you free of charge.
Situation 4 Quality problem with big batches if you buy your own brand within warranty time: You give your customer a new genset for free firstly→We would compensate you in batches in future orders.
OEM Service
※ Design team size: 10 designers.
※ What can we design for you: sticker, carton, logo, poster…
※ Design time required after receving your deposit
Sticker desgin: within 2 days
Carton desgin: within 2 days
Logo: within 1 day
Poster: within 1 week
……
