home – power generator – OHV low noise electric starter diesel generator
model: BS7500DSE
OHV low noise electric starter diesel generator
within 25 days delivery time after receiving the deposit！
Launch of OHV low noise diesel generator, BISON diesel generator factory utilizes overhead valve (OHV) technology to output excellent fuel efficiency.
Core competitive advantages of OHV diesel generator:
- Advanced OHV technology: Experience the power of BISON’s cutting-edge overhead valve (OHV) technology that delivers significant improvements in fuel efficiency and engine lifespan.
- Superior noise reduction: With cutting-edge noise dampening technology, this electric starter diesel generatoroffers an exceptionally quiet operation, making it ideal for use in residential areas or any setting where noise is a concern.
- Reliable electric starter: Enhance user convenience with a dependable electric starter that ensures BS7500DSE generator starts quickly and effortlessly, eliminating the inconvenience of manual start-ups.
- Robust and dependable: Built to last, BISON OHV low noise generators are constructed with high-grade materials engineered to perform consistently in all conditions.
features
User friendly design
BS7500DSE is a white box-type generator with flexible wheels.Featuring a user-friendly, integrated control panel that simplifies operations, it includes digital displays for monitoring essential metrics such as fuel level, engine status, and maintenance indicators.
The BISON factory emphasizes environmental sustainability and aims to reduce emissions, and the generator complies with international environmental standards, including EPA and CE certification. This aspect ensures the compatibility of OHV electric starter generator with markets with strict environmental regulations.
Always provide high quality service
BISON is a leading brand in the global diesel generator industry, we focus on innovation, quality and commitment to sustainable development.
Our dedicated service team is available 24/7 to assist with any concerns or technical queries, helping ensure your operations run smoothly at all times.
BISON’s expansive logistics network guarantees fast and reliable shipping of generators and parts across the globe, directly to your location.
specifications
| output | |
|---|---|
| rated power | 6.0 KW |
| maximum power | 6.5 KW |
| Phase | single-phase / three-phases (optional) |
| AC voltage | depends on your country’s voltage |
| single-phase AC amperage | running power ÷ using voltage |
| three-phase AC amperage | running power ÷ using voltage ÷ 1.3856 |
| frequency | 50 / 60 HZ |
| continuous operating time | 13 h |
| engine & emission | |
|---|---|
| engine type | 4-stroke, OHV, air-cooled |
| engine model name | BS168F-1 |
| bore × stroke | 68 × 45 MM |
| engine displacement | 196 CC |
| engine speed | 3000(50 Hz) / 3600(60 Hz) RPM |
| recoil start | yes |
| electric start | optional |
| alternator | |
|---|---|
| winding material | 100% copper winding |
| power factor | 1.0 (single-phase) / 0.8 (three-phase) |
| fuel system | |
|---|---|
| fuel tank capacity | 15 l |
| oil capacity | 0.6 l |
| packaging | |
|---|---|
| carton dimensions (no wheels & handles) | 605 × 440 × 440 MM |
| generator net weight | 35 KGS |
| carton gross weight | 37 KGS |
optional
If your customers have remote start requirements, you should choose this option.
remote start
easy to move the generator
The customers who have high-end pursue of generator should choose this option.
digital display
easy to monitor the generator
The generators above 7 kilowatts or have three-phase voltage should choose this option.
industrial socket
power for industrial use
When you take generators as backup power, you could choose this. ATS is not necessary for small kilowatts.
ATS
automatically start without human intervention required
If the winter temperature in your area is below 0 ℃, you should choose this option.
glow plug
help to start in low temperature
factory
overview
how we test the gasoline generator
Improve the lift of the camshaft, determine the trajectory curve, and better analyze the state of the fuel injection pump and fuel injector.
camshaft test
Ensure that the gas tightness of the cylinder head meets the requirements and improves the performance stability of the generator.
cylinder head test
The oil central processor, all oil must be filtered and then used, reducing the wear of the parts.
oil quality testing
Make sure that all data indicators of the cylinder are normal and can meet the assembly requirements of the engine.
cylinder test
Crankcase has a oil leakage test to ensure that there is no oil leakage problem.
crankcase seal test
Ensure bearing sealing and no oil leakage
bearing seal test
Makes the surface of spare parts smoother and reduces wear.
honing parts
Correct the axis offset, skew, and other defects of the processed hole to ensure the position accuracy of the hole, while also obtaining the required hole diameter tolerance and surface roughness.
precision boring process
Make sure the connection between the cylinder head and the box is firm and there is no possibility of air or water leakage.
torque test
Make sure the engine is running normally and stably without any abnormal noise.
engine test
After the engine test, clean the internal residue to reduce the damage of the parts.
residue cleaning
Ensure the sealing of alternator is stable.
alternator air gap
After the alternator supplier’s first test, we would test it ourselves again to ensure alternator don’t have quality problem.
alternator 100% test
Make sure the generator can operate properly in low temperature conditions.
low temperature test
Well-packaged and ensure the safety of the generator.
packaging
